C2G 2m Mini DisplayPort Male to Single Link DVI-D Male Adapter Black 84335
C2G 2m Mini DisplayPort Male to Single Link DVI-D Male Adapter Black 84335
Regular price
£7.60
Regular price
£9.20
Sale price
£7.60
Taxes included.

C2G 2m Mini DisplayPort Male to Single Link DVI-D Male Adapter Black - 84335
C2G 2m Mini DisplayPort Male to Single Link DVI-D Male Computer Monitor Adapter Cable Full HD Black
Connect the Mini DisplayPort or Thunderbolt output of a computer to the DVI input of a computer monitor. This adapter cable is an ideal solution for connecting the Mini DisplayPort or Thunderbolt output of a small laptop or tablet to a computer monitor which accepts a DVI-D input. This cable carries a digital video signal, supports up to a 1920 x 1200 resolution and meets the requirements of high performance applications.
C2G 2m Mini DisplayPort Male to Single Link DVI-D Male Computer Monitor Adapter Cable Full HD Black
Connect the Mini DisplayPort or Thunderbolt output of a computer to the DVI input of a computer monitor. This adapter cable is an ideal solution for connecting the Mini DisplayPort or Thunderbolt output of a small laptop or tablet to a computer monitor which accepts a DVI-D input. This cable carries a digital video signal, supports up to a 1920 x 1200 resolution and meets the requirements of high performance applications.
- Directly connect a Mini DisplayPort output to a Single Link DVI-D input
- Carries a digital video signal
- Supports up to a 1920 x 1200 resolution
- Voltage Rating: 30v
- Conductor Resistance: @ 20°C max
- Insulation Resistance: 10MΩ/km
- Time Delay: 5.2ns/m (max)
- Attenuation:- 5.02dB @ 100-450MHz. - 7.69dB @ 1GHz. - 12.595dB @ 2GHz. - 17.495dB @ 3GHz. - 22.395dB @ 4GHz. - 27.295dB @ 5GHz. - 32.195dB @ 6GHz. - 37.095dB @ 7GHz.
- Operating Temperature: 0°C to 50°C
- Storage Temperature: -25°C to 70°C
- Approvals: CE
- Conductor (2 conductor, 5 pair)
- Conductor: 32AWG (7/0.08TC)
- Insulation: FM-PE, ID:0.63±0.05mm
- Colour: White/Brown, White/Red, White/Orange, White/Green, White/Blue
- Drain: 32AWG (7/0.08TC)
- Shield: Aluminium Wrap, Coverage—100%
- Conductor (5 conductors)
- Conductor: 32AWG (7/0.08TC)
- Insulation: HD-PE, ID:0.5±0.05mm
- Colour: Red/Orange/Yellow/Green/ White
- Overall Cable
- Jacket: PVC
- Shield: Aluminium Foil—Coverage 100%, Braid—16/9/0.12
- Drain: 2:30AWG (7/0.08 BC)
- Outside Diameter: 5.2±0.2
